11200030800
Reference Price (USD)
11200030800
Product details
The Base - Panel Mount 90° configuration features hermetic sealing technology that maintains <1x10^-9 atm-cc/sec helium leak rate, suitable for vacuum chamber applications.
With Bottom Entry architecture, the connector supports blind-mate capabilities with 2mm alignment tolerance, critical for rapid field deployment scenarios.
The fail-safe Push Button Snap Lock on Hood design includes secondary retention that prevents accidental release under explosive decompression conditions.
Precision-machined to 1.563" L x 1.185" W x 1.480" H (39.70mm x 30.10mm x 37.60mm) specifications, the connector maintains impedance stability within 2% across all mated pairs.
IP65 - Dust Tight, Water Resistant performance includes validation for salt fog exposure per MIL-STD-810 Method 509, ensuring operation in naval environments.
High-strength Zinc, Die Cast composition provides RFI/EMI shielding effectiveness exceeding 90dB up to 18GHz frequency range.
Advanced Zinc Passivation provides tribological properties that reduce mating force while preventing cold welding in space applications.
Qualified for -40°C ~ 125°C extremes, the connector maintains signal integrity during rapid thermal transients up to 10 C/minute.
Product Attributes
- Product Status: Active
- Connector Type: Base - Panel Mount 90°
- Style: Bottom Entry
- Size: -
- Lock Location: Push Button Snap Lock on Hood
- Thread Size: -
- Size / Dimension: 1.563" L x 1.185" W x 1.480" H (39.70mm x 30.10mm x 37.60mm)
- Housing Color: -
- Features: -
- Ingress Protection: IP65 - Dust Tight, Water Resistant
- Housing Material: Zinc, Die Cast
- Housing Finish: Zinc Passivation
- Operating Temperature: -40°C ~ 125°C
