814-22-056-30-002101

The 814-22-056-30-002101 from Mill-Max Manufacturing Corp. represents cutting-edge engineering in Rectangular Connectors - Spring Loaded, designed for high-density interconnect solutions. This advanced connector system ensures optimal signal transmission while maintaining robust mechanical integrity across demanding applications.Engineered with Piston configuration, this component delivers superior mating cycle performance, particularly in vibration-prone environments where contact reliability is critical.With 56 precision contacts arranged in optimized arrays, the connector achieves balanced current distribution and minimized insertion loss for high-speed data transmission.The 0.100" (2.54mm) pitch configuration enables compact PCB layouts while maintaining adequate creepage distance for voltage isolation requirements in industrial automation systems.Featuring 2 rows of contacts, this design provides flexible routing options for complex circuit architectures without compromising signal integrity.The 0.100" (2.54mm) row spacing accommodates standard PCB design rules while providing sufficient clearance for impedance-controlled routing in RF applications.The Surface Mount mounting interface simplifies assembly processes while ensuring mechanical stability under thermal cycling conditions common in automotive electronics.Constructed from Copper Alloy, the contact system exhibits exceptional spring characteristics and corrosion resistance for long-term reliability in harsh operating environments.Gold plating enhances conductivity while preventing fretting corrosion, crucial for maintaining low contact resistance over extended service life.Precision-controlled 20.0µin (0.51µm) finish thickness guarantees consistent mating performance while optimizing cost-efficiency in high-volume production.
